120 / 24D Super Fine Wire Drawing Machine For 0.025-0.06mm Finished Product

Name: 120 24D Super Fine Wire Drawing Machine For 0025006mm Finished Product
Brand: Newlead
Price: 1 USD

Quality 120 / 24D Super Fine Wire Drawing Machine For 0.025-0.06mm Finished Product for sale

Place of Origin : Jiangsu, China (Mainland)

Brand Name : Newlead

Model Number : 120 / 24D

Certification : ISO9001:2008

Price : Negotiation | 1 Set/Sets (Min. Order)

MOQ : 1 Set/Sets

Supply Ability : 10 sets in 60 days

Delivery Time : 60 days

Packaging Details : wooden pallet or by wooden box

Condition : New

Inlet Diameter : 0.07-0.18mm

Outlet Diameter : 0.025-0.06mm

Voltage : 380V OEM

Power(W) : 3KW+3KW

Dimension(L*W*H) : 1190L*1160W*1810H

Weight : 1200KG

Warranty : 2 Years

After-sales Service Provided : Engineers available to service machinery overseas

Contact Now

120 / 24D Ultra super fine Wire Draw machine for 0.025-0.06mm finished product

Product Description

120/24D Ultra-fine Wire Draw machine is a full computer control, automatic control of the whole process of line up, the four main technical parameters of the direct display, Using color touch screen control display, sliding parameter, line speed, Recovery line speed , current weight and meters, The output and the output parameters of the 3 shift 4 operation class are directly displayed. parameters display and has memory function, the machine adopts wire drawing, winding, double frequency without tension rod PLC control, cable with synchronous servo motor, wheel round-trip cable, this machine line high speed, large capacity, Stepless frequency conversion speed ,And so on Characteristics.

Technical parameters

Serial number	Name	Data
1	Inlet	φ0.070mm--φ0.180mm
2	Outlet	φ0.025mm--φ0.06mm
3	Max speed	2000m/min (12--40kg Capacity of receiving line)
4	Max drafts	24(1+11+11+1)
5	Reduction rate	8% Final:7%
6	Wire drawing mode	Up and down 2 ,4 groups of pulley ,Double mould rack ,Spray sliding type
7	The cone pulley	φ120×11,The 4 group,Capstanφ120,The 1 group,Ceramic spray cone pulley
8	Main motor	3KW Three-phase AC
9	Take up motor	3KW Three-phase AC
10	Traversing motor servo	200W〈20B30CB〉Single phase AC
10	servo motor	80W〈70TDY115〉Three-phase AC
11	water pump motor	120W〈15SJCB--22〉Three phase AC pipeline pump (Customer matching )
12	wire drawing light	220V 30W
13	Take up light	220V 7W-11W Energy saving light
14	Electromagnetic Stop device	24V 30W
15	speed control mode	Control small electric cabinet panel multi ring position, potentiometer speed regulation
16	traverse method	Ball screw drive, servo motor positive and negative, maximum width 160mm～280mm
17	lubricating system	Fan shaped spray type (With water tank, water pump, put the line rack )
18	Dimension	Length×width× height 1180×1160×1810mm
19	Gross weight	1.18T
20	Spool size of receiving line	Outer circle total height ,Bottom width,The inner hole)φ200×216×φ160 ×180×φ80 (Steel plate ,Dynamic balance requirement)Big)φ280×270×φ215×250×φ125 (Steel plate ,Dynamic balance requirement)

Our Services

Pre-sale training:

In order to guarantee the customers fully to operate the machine, if the customer need, we can help customer training, includes:
1)Correct operating mode
2)Correct maintenance way
3)Remove simple problem of our product

After-sale maintenance service is:

1,Both mechanical and electrical parts are provided 2 years limited warranty.
2,Manufacturing experience with more than 20years
We shall work with you as a team and to win as a team.
We provide not only quality products but also best service to you.
